FLYWHEEL MAGNEO (KOKUSAN DENKI)
TS90
Flywheel magneo (kokusan denki) diagram TS90
FLYWHEEL MAGNEO (KOKUSAN DENKI) TS90
×
prices are in EUR
ref
part #
description
quantity
1
3210025020
ref: 1
MAGNETO ASSEMBLY
€ 75.00
2
3210125020
ref: 2
STATOR ASSEMBLY
€ 75.00
3
3214012020
ref: 3
COIL
€ 62.00
4
3213012020
ref: 4
COIL
€ 41.50
5
3212012020
ref: 5
COIL,LIGHTING
€ 24.50
6
3224012020
ref: 6
POINT ASSEMBLY,CONTACT
€ 42.00
7
3234112021
ref: 7
CONDENSER
€ 27.00
8
3233803020
ref: 8
FELT,OIL
€ 2.00
9
3274105000
ref: 9
GROMMET
€ 0.00
10
0231104128
ref: 10
SCREW
€ 2.00
11
0211104308
ref: 11
SCREW
€ 1.50
12
0211104068
ref: 12
SCREW
€ 2.00
13
0832121048
ref: 13
LOCK WASHER
€ 2.00
14
0832221048
ref: 14
WASHER
€ 2.00
15
3210225020
ref: 15
ROTOR,FLYWHEEL
€ 200.50
16
0914010003
ref: 16
NUT (10MM)
€ 3.50
17
0832121108
ref: 17
LOCK WASHER
€ 2.00
18
0832211108
ref: 18
WASHER
€ 2.50
19
0212106168
ref: 19
SCREW
€ 2.00
20
3341025020
ref: 20
COIL ASSEMBLY,IGNITION
€ 184.50
21
0121105168
ref: 21
CROSS HEAD SCREW
€ 1.00
22
0832121058
ref: 22
LOCK WASHER
€ 2.00
23
3344525000
ref: 23
IGNITION COIL COVER
€ 0.00
