TRANSMISSION

ref

part #

description

quantity

1

2412125001
ref: 1
L.=179.5(7.06),N.T.=11

SHAFT,COUNTER

€ 30.50

2

2413125000
ref: 2

SHAFT,DRIVE

€ 60.00

3

2422125000
ref: 3
N.T.=15

GEAR,SECOND DRIVE

€ 20.00

4

2423125000
ref: 4
N.T.=18

GEAR,THIRD DRIVE

€ 23.00

5

2424125000
ref: 5
N.T.=20

GEAR,FOURTH DRIVE

€ 16.50

6

2425125001
ref: 6
N.T.=23

GEAR,FIFTH DRIVE

€ 31.00

7

2431025001
ref: 7
N.T.=31

GEAR,FIRST DRIVEN

€ 16.50

8

2432125000
ref: 8
N.T.=28

GEAR,SECOND DRIVEN

€ 19.00

9

2433125000
ref: 9
N.T.=25

GEAR,THIRD DRIVEN

€ 43.50

10

2434125000
ref: 10
N.T.=22

GEAR,FOURTH DRIVEN

€ 18.00

11

2435125001
ref: 11
N.T.=20

GEAR,FIFTH DRIVEN

€ 36.00

12

2626012000
ref: 12
N.T.=26

GEAR,KICK STARTER IDLE

€ 29.50

13

2628019000
ref: 13
N.T.=16

GEAR,KICK STARTER DRIVEN(NT:16

€ 52.00

14

0938017001
ref: 14

CIRCLIP

€ 2.00

15

0926230002
ref: 15
30X62X10(1.18X2.44X0.39)

BEARING

€ 30.00

16

0811360010
ref: 16
12X28X8(0.47X1.10X0.31)

BALL BEARING

€ 15.00

17

0811362040
ref: 17

Bearing

€ 28.00

18

0928325034
ref: 18
25X40X7(0.98X1.57X0.28)

OIL SEAL

€ 6.50

19

0931915002
ref: 19

BUSHING

€ 8.00

20

0821112203
ref: 20
12X20X2(0.47X0.89X0.08)

WASHER

€ 1.50

21

0938020003
ref: 21

CIRCLIP

€ 3.00

22

0916720007
ref: 22

WASHER

€ 3.00

23

0821115241
ref: 23

WASHER,THRUST

€ 4.00

24

2474125000
ref: 24

PLATE,COUNTERSHAFT BEARING

€ 6.50

25

0212106108
ref: 25

SCREW

€ 1.50

26

2760025010
ref: 26
#428X114?

CHAIN ASSEMBLY,DRIVE

€ 46.50

27

2762008011
ref: 27

JOINT ASSEMBLY,CHAIN

€ 7.00

28

2751120700
ref: 28
N.T.=14

SPROCKET,ENGINE

€ 33.00

29

0918020035
ref: 29
20X25X13.5(0.79X0.98X0.53)

SPACER (20X25X13.5)

€ 4.50

30

0928020001
ref: 30

O RING(D:1,ID:19.5)

€ 2.00

31

0916720006
ref: 31

WASHER,LOCK

€ 3.00

32

0914020001
ref: 32

NUT

€ 3.50

33

0926321004
ref: 33
21X35X2.8(0.83X1.38X0.11)

BEARING 21X35X2.8

€ 11.50

34

0916021007
ref: 34
21X30X0.8(0.83X1.18X0.03)

WASHER(21X30X0.8)

€ 3.50
