REAR CALIPER

VS1400GLP BOULEVARD S83 2005 (K5) CALIFORNIA (E33)

Rear caliper diagram VS1400GLP BOULEVARD S83 2005 (K5) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

6910038B50999
ref: 1

CALIPER ASSY,RR

€ 707.00

6910038851
ref: 2

PISTON SET

€ 176.00

6910038831
ref: 3

SEAL SET,PISTON

€ 38.50

5914516700
ref: 4

BOLT,HOUSING

€ 8.00

5914316700
ref: 5

SPRING

€ 7.50

6914145000
ref: 6

PIN,PAD

€ 6.50

6914245000
ref: 7

CLIP,PAD PIN

€ 4.50

5915124A01
ref: 8

COVER

€ 18.00

5912118410
ref: 9

BLEEDER

€ 8.00

5515666310
ref: 10

CAP,BLEEDER PLUG

€ 6.00

6910038880
ref: 11

PAD & SHIM SET (NAS)

€ 102.50

5937133410
ref: 12

SHIM,PAD

€ 15.00

5937133420
ref: 13

SHIM

€ 14.00

0713010203
ref: 14
07130-1020B

BOLT

€ 3.50
