Buy Suzuki VS Parts Online


FRONT CALIPER (MODEL N)

VS800GL INTRUDER 1993 (P) USA (E03)

Front caliper (model n) diagram VS800GL INTRUDER 1993 (P) USA (E03)

FRONT CALIPER (MODEL N) VS800GL INTRUDER 1993 (P) USA (E03)
FRONT CALIPER (MODEL N) VS800GL INTRUDER 1993 (P) USA (E03)
FRONT CALIPER (MODEL N) VS800GL INTRUDER 1993 (P) USA (E03)
prices are in EUR
ref
part #
description
quantity

5910038A01
ref:
59100-38A02-999
CALIPER ASSEMBLY,FRONT,RIGHT
€ 595.50
1
6910024821
ref: 1
PISTON SET
6910024821
€ 102.00
2
5513666310
ref: 2
69107-38B00
SEAL,FR CALIPE
5513666310
€ 8.50
3
6910845000
ref: 3
BOOT,PISTON
6910845000
€ 10.00
4
6910734200
ref: 4
SEAL,JOINT
6910734200
€ 12.00
5
5913038B10
ref: 5
59100-38820
PAD
€ 41.50
6
5937133410
ref: 6
SHIM,PAD
5937133410
€ 15.00
7
5914516700
ref: 7
BOLT,HOUSING
5914516700
€ 8.00
8
5914316700
ref: 8
SPRING
5914316700
€ 7.50
9
6914145000
ref: 9
PIN,PAD
6914145000
€ 6.50
10
6914245000
ref: 10
CLIP,PAD PIN
6914245000
€ 4.50
11
5915138B00
ref: 11
59151-38B01
COVER,CALIPER
€ 58.00
12
5915224A00
ref: 12
CAP,CALIPER
5915224A00
€ 23.50
13
5912118410
ref: 13
BLEEDER
5912118410
€ 8.00
14
5515666310
ref: 14
CAP,BLEEDER PLUG
5515666310
€ 6.00
15
5915338B00
ref: 15
59153-38B10
SCREW,CALIPER COVER (4X
€ 7.50
16
0910610038
ref: 16
BOLT(10X33)
0910610038
€ 4.50
17
0925008014
ref: 17
CAP(OD:12)
0925008014
€ 3.50
