FRONT BRAKE HOSE

VZR1800N BOULEVARD M109R 2006 (K6) CALIFORNIA (E33)

Front brake hose diagram VZR1800N BOULEVARD M109R 2006 (K6) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

1-1

5948048G00
ref: 1-1
59480-48G20

HOSE,FR BRAKE

€ 210.50

1-2

5948048G20
ref: 1-2

HOSE,FR BRAKE NO.1

€ 210.50

1-3

5948048G10
ref: 1-3

HOSE,FR BRAKE

€ 174.00

015470625A
ref: 2

BOLT

€ 2.50

0936010062
ref: 3

BOLT UNION

€ 5.00

0916110009
ref: 4

WASHER(10X15X1.5)

€ 2.00

5926048G00
ref: 5

CLAMP,FR BRAKE HOSE,R

€ 19.50

5927048G00
ref: 6

CLAMP,FR BRAKE HOSE,L

€ 19.00

5926648G00
ref: 7

CLAMP,FR BRAKE HOSE

€ 11.50

0940718402
ref: 8

CLAMP(L:165)

€ 2.50

015500812A
ref: 9

BOLT

€ 2.50
