TURNSIGNAL LAMP (VZR1800K8/K9/NK8/NK9)

VZR1800Z BOULEVARD M109R 2007 (K7) CALIFORNIA (E33)

Turnsignal lamp (vzr1800k8/k9/nk8/nk9) diagram VZR1800Z BOULEVARD M109R 2007 (K7) CALIFORNIA (E33)

TURNSIGNAL LAMP (VZR1800K8/K9/NK8/NK9) VZR1800Z BOULEVARD M109R 2007 (K7) CALIFORNIA (E33)

TURNSIGNAL LAMP (VZR1800K8/K9/NK8/NK9) VZR1800Z BOULEVARD M109R 2007 (K7) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

1-1

3560138AF0
ref: 1-1

LAMP ASSY,FR TURN SIGNAL,R

€ 68.50

1-2

3560238AF0
ref: 1-2

LAMP ASSY,FR TURN SIGNAL,L

€ 68.50

2

3561038AA0
ref: 2

LENS

€ 19.50

3

3563038AA0
ref: 3

LENS

€ 19.50

4

3562338AA0
ref: 4

SCREW(4X10)

€ 4.00

5

0947112083
ref: 5
09471-12128

BULB(12V21/5W)

€ 6.00

6

021420612A
ref: 6

SCREW

€ 2.00

7

0932009016
ref: 7

CUSHION

€ 2.50

8

035410510A
ref: 8

SCREW

€ 1.50

9

3564148G00
ref: 9

STAY,FR TURNSIGNAL

€ 112.50

10

0913906146
ref: 10

SCREW(6X16)

€ 3.00

11-1

3560348EC0
ref: 11-1

LAMP ASSY,RR TURNSIGNAL,R

€ 68.50

11-2

3560438AE0
ref: 11-2

LAMP ASSY,RR TURNSIGNAL,L

€ 68.50

12

3563038AE1
ref: 12

LENS

€ 19.50

13

3561038AE1
ref: 13

LENS

€ 19.50

14

3562338AA0
ref: 14

SCREW(4X10)

€ 4.00

15

0947112045
ref: 15

BULB(12V21W)

€ 5.00

16

3569517C00
ref: 16

SPACER,RR TURNSIGNAL

€ 3.00

17

0916010501
ref: 17

WASHER(10.5X30X2.3)

€ 2.50

18

083100010A
ref: 18

NUT

€ 2.00

19

3861003F00
ref: 19

RELAY ASSY,TURNSIGNAL LAMP

€ 88.50
