FENDER

DR-Z110 2003 (K3) USA (E03) DRZ110 DR Z110

Fender diagram DR-Z110 2003 (K3) USA (E03) DRZ110 DR Z110

prices are in EUR

ref

part #

description

quantity

132

KK132G0625
ref: 132
K132B-A0625

BOLT,FLANGED S

€ 2.00

35004

K350041457267
ref: 35004

FENDER-FRONT

€ 28.50

35019

K350191399
ref: 35019

FLAP

€ 11.50

35022

K350221342267
ref: 35022

FENDER-COMP-REAR

€ 32.50

92015

K920151078
ref: 92015
K9221-00630

NUT,FLANGED,6MM

€ 1.50

92022

KK92022125
ref: 92022

WASHER,6.5X20X1.6

€ 1.00

92143

K921431087
ref: 92143

COLLAR

€ 2.50

92150

K921501506
ref: 92150

BOLT,FLANGED,6X16

€ 4.50

92150A

K921501892
ref: 92150A

BOLT,6X20

€ 3.50

92152

K921521255
ref: 92152

COLLAR

€ 3.50
