GEAR CHANGE DRUM/SHIFT FORK

DR-Z110 2003 (K3) USA (E03) DRZ110 DR Z110

Gear change drum/shift fork diagram DR-Z110 2003 (K3) USA (E03) DRZ110 DR Z110

prices are in EUR

ref

part #

description

quantity

235

KK235B0514
ref: 235

SCREW-PAN-WP-CROS

€ 0.00

610

KK610A0408
ref: 610

ROLLER,4X8

€ 1.50

13140

K131401263
ref: 13140
K1314-00058

FORK-SHIFT

€ 61.50

13140A

K131401289
ref: 13140A
K1314-00059

FORK-SHIFT

€ 26.00

13141

K131411226
ref: 13141
K1314-10038

DRUM-CHANGE

€ 52.50

13145

K131451093
ref: 13145
K1314-51081

CAM-CHANGE DRUM

€ 8.00

13151

K131511082
ref: 13151
K1315-10021

SWITCH-COMP

€ 24.50

13280

K132801228
ref: 13280

HOLDER

€ 5.50

49047

K490471058
ref: 49047

ROD-SHIFT

€ 8.50

92043

K920431385
ref: 92043

PIN

€ 4.50

92055

KK92055091
ref: 92055

RING-O

€ 4.50

92144

K921441245
ref: 92144

SPRING

€ 2.50

92150

K921501433
ref: 92150

BOLT,SOCKET,6X30

€ 3.50
