AIR CLEANER

DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

Air cleaner diagram DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

prices are in EUR

ref

part #

description

quantity

1370008G01
ref: 1

CLEANER ASSY,AIR

€ 161.00

1374008G01
ref: 2

CAP,AIR CLEANER

€ 17.00

1374608G00
ref: 3

GASKET (NAS)

€ 5.50

1378008G00
ref: 4

FILTER

€ 28.50

1379108G00
ref: 5

HOLDER,FILTER

€ 8.50

1379213A01
ref: 6

WASHER,AIR CLEANER

€ 3.00

1383108G00
ref: 7
13831-31G00

BOLT, WING

€ 5.00

1382614D01
ref: 8

CLAMP,OUTLET TUBE

€ 7.50

0940248208
ref: 9

CLAMP

€ 4.50

1388108G00
ref: 10

TUBE,OUTLET

€ 35.50

1385308G00
ref: 11

TUBE,BREATHER

€ 14.50

1385814D10
ref: 12
13858-14D20

JOINT

€ 6.00

0940114301
ref: 13

CLIP

€ 2.00

1389108G00
ref: 14

TUBE,INLET

€ 17.00

1381003G00
ref: 15

TRAP,FLAME

€ 7.00

1368119B00
ref: 16

CAP,DRAIN

€ 3.00

0214205163
ref: 17
02142-0516A

SCREW

€ 2.50

0914806021
ref: 18

NUT

€ 3.00

015500612B
ref: 19

BOLT

€ 2.50
