CYLINDER

DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

Cylinder diagram DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

CYLINDER DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

CYLINDER DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

prices are in EUR

ref

part #

description

quantity

1

1121044A110F0
ref: 1

CYLINDER

€ 252.00

2

0910308378
ref: 2

BOLT(8X155)

€ 4.50

3

0910308379
ref: 3

BOLT(8X165)

€ 4.50

4

0916008039
ref: 4

WASHER(8.5X19X2.3)

€ 2.00

5

0916808021
ref: 5

GASKET(8.5X17X2.3) (NAS)

€ 3.00

6

014210625B
ref: 6

BOLT,STUD

€ 2.50

7

083161006B
ref: 7

NUT

€ 2.50

8

1124105311
ref: 8

GASKET,CYLINDER (NAS)

€ 4.50

9

0421111149
ref: 9

PIN

€ 2.00
