CRANKSHAFT

DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

Crankshaft diagram DR-Z125L 2010 (L0) USA (E03) DRZ125L DR Z125L

prices are in EUR

ref

part #

description

quantity

1220005240
ref: 1

CRANKSHAFT ASSY

€ 312.50

1210505821
ref: 2

CONNECTING ROD SET

€ 163.00

09263280270B0
ref: 3

BEARING(28X36X15.8)

€ 24.50

1222105210
ref: 4

CRANKSHAFT,R

€ 150.50

1226105210
ref: 5

CRANKSHAFT,L

€ 156.00

0926228014
ref: 6

BEARING(28X68X18)

€ 40.00

0926235038
ref: 7

BEARING(35X72X17)

€ 38.00

0928212009
ref: 8

SEAL,OIL(12X21X7)

€ 9.00

1632105201
ref: 9

GEAR,OIL PUMP DRIVE

€ 18.00

21111052000C0
ref: 10

GEAR,PRIMARY DRIVE(NT:17)

€ 33.00

0914016019
ref: 11

NUT

€ 4.00

0916616012
ref: 12

WASHER

€ 1.50

0942104004
ref: 13

KEY

€ 3.50

12111052020F0
ref: 14

PISTON

€ 39.50

1214001410
ref: 15

RING SET,PISTON

€ 37.50

1215105220
ref: 16

PIN,PISTON

€ 6.50

0938114001
ref: 17

RING,SNAP 14MM

€ 1.50

1210005200050
ref: 18

PISTON SET(OS:0.5)

€ 70.00
