SEAT (MODEL K2/K3/K4)

DR-Z400 2001 (K1) USA (E03) DRZ400 DR Z400

Seat (model k2/k3/k4) diagram DR-Z400 2001 (K1) USA (E03) DRZ400 DR Z400

SEAT (MODEL K2/K3/K4) DR-Z400 2001 (K1) USA (E03) DRZ400 DR Z400

SEAT (MODEL K2/K3/K4) DR-Z400 2001 (K1) USA (E03) DRZ400 DR Z400

prices are in EUR

ref

part #

description

quantity

1

4510029F406BY
ref: 1

SEAT ASSY(BLACK)

€ 321.00

2-1

4514912C00
ref: 2-1

CUSHION,SEAT(40X20X6)

€ 3.00

2-2

4514931300
ref: 2-2

CUSHION,SEAT(40X20X15)

€ 2.00

3

0932110022
ref: 3

CUSHION

€ 2.00

4

0911606182
ref: 4

BOLT(6X20)

€ 3.00
