STEERING STEM
DL1000 VSTROM 2003 (K3) USA (E03)
Steering stem diagram DL1000 VSTROM 2003 (K3) USA (E03)
STEERING STEM DL1000 VSTROM 2003 (K3) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5141006G00
ref: 1
STEM,STEERING
€ 1,002.00
2
5164412C00
ref: 2
SEAL,STEERING LWR
€ 5.50
3
0926730010
ref: 3
BEARING(30X55X17)
€ 46.50
4
0926730010
ref: 4
BEARING(30X55X17)
€ 46.50
5
5163133E00
ref: 5
NUT,STEERING STEM
€ 12.00
6
5164133E00
ref: 6
WASHER,STEERING STEM
€ 3.00
7
5164324F10
ref: 7
COVER,STEERING UPR
€ 27.50
8
5164412C00
ref: 8
SEAL,STEERING LWR
€ 5.50
9
5116635F00
ref: 9
BOLT
€ 6.50
10
5131106G00
ref: 10
HEAD,STEERING STEM
€ 456.50
11
5116635F00
ref: 11
BOLT
€ 6.50
12
5135306G00
ref: 12
NUT
€ 18.00
12A
5135327G00
ref: 12A
NUT
€ 22.00
13
5135406G00
ref: 13
WASHER
€ 7.50
14
5622127E00
ref: 14
HOLDER,HANDLE UNDER
€ 48.50
15
5632127E00
ref: 15
BOLT,HANDLE HOLDER(10X70)
€ 6.00
16
5624127E00
ref: 16
CUSHION,RUBBER UPR
€ 32.50
17
5626042A00
ref: 17
RUBBER,LWR
€ 34.00
18
5624342A00
ref: 18
SPACER
€ 6.00
19
0831931107
ref: 19
NUT
€ 3.00
20
5621132F00
ref: 20
HOLDER,HANDLE UPR
€ 48.50
21
5132106G00
ref: 21
BOLT
€ 5.00
22
0916408015
ref: 22
WASHER
€ 3.00
23
0925006011
ref: 23
CAP(OD:11)
€ 2.50
