REAR SWINGING ARM (MODEL Z)
DR250 1982 (Z) USA (E03)
Rear swinging arm (model z) diagram DR250 1982 (Z) USA (E03)
REAR SWINGING ARM (MODEL Z) DR250 1982 (Z) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
6100038220
ref: 1
61000-38230
SWING ARM ASSEMBLY,REAR
€ 222.50
2
6126138200
ref: 2
BUSHING,RR SWGARM PIVOT
€ 13.50
3
683811410064D
ref: 3
EMBLEM,SWING ARM
€ 3.50
4
6125138200
ref: 4
SPACER,RR SWGARM PIVOT OUTER
€ 16.50
5
0928620001
ref: 5
SEAL,OIL(20X27X5)
€ 2.50
6
0821115341
ref: 6
WASHER
€ 2.00
7
6126238200
ref: 7
61262-22A00
COVER,REAR SWING ARM DUST
€ 7.50
8
0832211148
ref: 8
08322-01147
WASHER
€ 2.00
9
0831921148
ref: 9
08319-2114A
NUT 14MM
€ 3.00
10
6121138200
ref: 10
64711-26B00
SHAFT,REAR SWING ARM
€ 33.00
11
6127338210
ref: 11
61273-38211
BUFFER,CHAIN TOUCH DEFLECTOR
€ 17.00
12
643100531108C
ref: 12
LINK,REAR TORQUE
€ 11.50
13
0911108050
ref: 13
BOLT
€ 2.50
14
0911108013
ref: 14
BOLT(8X26.5)
€ 3.00
15
0832121088
ref: 15
08321-01087
LOCK WASHER
€ 2.00
16
0832211088
ref: 16
08322-01087
WASHER
€ 2.00
17
0914008008
ref: 17
NUT
€ 1.50
18
0411120208
ref: 18
04111-2020A
PIN 20X20
€ 1.50
