CRANKCASE LH COVER
GS500E 1983 (D) GENERAL EXPORT (E01)
Crankcase lh cover diagram GS500E 1983 (D) GENERAL EXPORT (E01)
CRANKCASE LH COVER GS500E 1983 (D) GENERAL EXPORT (E01)
×
prices are in EUR
ref
part #
description
quantity
1
1135147001
ref: 1
COVER,MAGNETO
€ 174.50
2
6823334200
ref: 2
EMBLEM,MAGNETO COVER
€ 28.50
3
1148347000
ref: 3
GASKET,MAGNETO COVER (MCA)
€ 16.50
4
0920613001
ref: 4
PIN
€ 2.50
5
0154706458
ref: 5
BOLT
€ 2.50
6
0154706408
ref: 6
BOLT (6X40)
€ 2.50
7
0154706358
ref: 7
BOLT (6X35)
€ 2.50
8
1130047822
ref: 8
COVER SET,ENGINE SPROCKET
€ 104.50
9
0835111009
ref: 9
NIPPLE
€ 32.00
10
0421109129
ref: 10
PIN
€ 2.00
11
0154706908
ref: 11
BOLT
€ 3.00
12
0154706808
ref: 12
BOLT
€ 3.50
13
0154706308
ref: 13
BOLT (6X30)
€ 2.50
14
1138747001
ref: 14
CAP,CLUTCH RELEASE ADJUST
€ 33.50
15
0154405168
ref: 15
BOLT 5X16
€ 2.00
16
1138247001
ref: 16
COVER,STARTER MOTOR
€ 19.00
17
0154705088
ref: 17
BOLT
€ 2.00
