BATTERY

GSF600S BANDIT 2001 (K1) USA (E03)

Battery diagram GSF600S BANDIT 2001 (K1) USA (E03)

prices are in EUR

ref

part #

description

quantity

3361032C10
ref: 1
33610-33E20

BATTERY ASSY(YTX9-BS,12V8AH)

€ 108.50

3365137000
ref: 2

PROTECTOR(170X95X3.0)

€ 5.00

3365137000
ref: 2

PROTECTOR(170X95X3.0)

€ 5.00

3365231F00
ref: 3

PROTECTOR(20X50X11)

€ 3.00

3365247D01
ref: 4

CUSHION,BATTERY

€ 7.00

3382031F00
ref: 5

WIRE,BATTERY PLUS LEAD

€ 22.50

3362416E00
ref: 6

CAP,BATTERY PLUS

€ 4.00

3386031F00
ref: 7

WIRE,BATTERY MINUS LEAD

€ 28.50
