HANDLE LEVER

GSXR1000 2002 (K2) USA (E03)

Handle lever diagram GSXR1000 2002 (K2) USA (E03)

HANDLE LEVER GSXR1000 2002 (K2) USA (E03)

HANDLE LEVER GSXR1000 2002 (K2) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

5711046E01
ref: 1

GRIP,THROTTLE

€ 26.00

2

5730033E01
ref: 2

LEVER ASSY,BRAKE

€ 44.00

3

5743117C00
ref: 3

BOLT,LEVER PIVOT

€ 8.00

4

0831610063
ref: 4
08316-1006B

NUT

€ 2.50

5

5746017C00
ref: 5
57460-17C01

SWITCH ASSEMBLY,STOP

€ 32.50

6

5746517C00
ref: 6

SCREW

€ 1.50

7

5721122D01
ref: 7
57211-22D01-291

GRIP,LEFT

€ 11.50

8

5750040F00
ref: 8
57500-40F10

LEVER ASSY,CLU

€ 97.00

9

5762140F00
ref: 9

LEVER,CLUTCH

€ 24.00

10

5743145C01
ref: 10

BOLT,LEVER PIVOT

€ 10.50

11

0831921063
ref: 11
08319-2106B

NUT

€ 2.50

12

5756005A00
ref: 12

SWITCH,CLUTCH

€ 11.00

13

0212203208
ref: 13
02122-0320A

SCREW

€ 2.00

14

0154706203
ref: 14
01547-0620B

SCREW

€ 2.50

15

5764133E20
ref: 15
57641-33E21

NUT,CABLE ADJUSTER

€ 24.00

16

5764433E00
ref: 16

SPRING,ADJUST

€ 6.50

17

5764233E00
ref: 17

SCREW,SPRING

€ 2.50
