OIL COOLER

GSXR750 2008 (K8) USA (E03)

Oil cooler diagram GSXR750 2008 (K8) USA (E03)

OIL COOLER GSXR750 2008 (K8) USA (E03)

OIL COOLER GSXR750 2008 (K8) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1660001H00
ref: 1

COOLER ASSY,OIL

€ 533.50

2

0928064003
ref: 2

O RING(D:3.1,ID:63.9)

€ 5.00

3

0910606099
ref: 3

BOLT(6X16)

€ 2.50

4

1646101H00
ref: 4

HOSE,OIL COOLER WATER INLET

€ 13.00

5

1647101H10
ref: 5

HOSE,OIL COOLER WATER OUTLET

€ 26.00

6

0940222512
ref: 6

CLAMP

€ 6.00

7

1651003G00X07
ref: 7
16510-07J00

FILTER ASSY,EN

€ 12.50
