FRONT FORK (GT750M

GT750 1973 1974 1975 1976 1977 (K) (L) (M) (A) (B) USA (E03)

Front fork (gt750m diagram GT750 1973 1974 1975 1976 1977 (K) (L) (M) (A) (B) USA (E03)

FRONT FORK (GT750M GT750 1973 1974 1975 1976 1977 (K) (L) (M) (A) (B) USA (E03)
FRONT FORK (GT750M GT750 1973 1974 1975 1976 1977 (K) (L) (M) (A) (B) USA (E03)
FRONT FORK (GT750M GT750 1973 1974 1975 1976 1977 (K) (L) (M) (A) (B) USA (E03)
prices are in EUR
ref
part #
description
quantity
6
5119631230
ref: 6
RING
5119631230
€ 7.50
7
5119531230
ref: 7
PIECE,OIL LOCK
€ 0.00
8
5157120520
ref: 8
DUST SEAL,FR FORK
5157120520
€ 19.50
9
5115601A00
ref: 9
RING,OIL SEAL STOPPER
5115601A00
€ 3.50
10
5115319D10
ref: 10
SEAL,OIL 35X48X11
5115319D10
€ 14.00
11
5118131030
ref: 11
O RING
5118131030
€ 3.50
12
5118931230
ref: 12
CAP
5118931230
€ 6.50
13
0833141309
ref: 13
CIRCLIP
0833141309
€ 2.00
15
5114748130
ref: 15
BOLT(8X27)
5114748130
€ 3.50
16
5114831030
ref: 16
GASKET (NAS)
5114831030
€ 4.00
17
0142108258
ref: 17
STUD 8X25
0142108258
€ 2.50
18
5113231030
ref: 18
HOLDER,AXLE
5113231030
€ 31.50
19
0832201087
ref: 19
WASHER
0832201087
€ 2.00
20
0832101087
ref: 20
WASHER,LOCK
0832101087
€ 2.00
21
0831000087
ref: 21
NUT
0831000087
€ 2.00
22
5118333030
ref: 22
GASKET (NAS)
5118333030
€ 6.50
23
0211204063
ref: 23
SCREW 4X6
0211204063
€ 2.00
