STAND - REAR BRAKE - RG125A 1988 (J) (E04 E15 E17 E18 E30)

ref

part #

description

quantity

1-1

4231036A00
ref: 1-1

STAND, PROP

€ 26.50

1-2

4231036A10
ref: 1-2
E15, E18, E2, F.NO.

STAND,PROP

€ 27.00

2-1

0944314024
ref: 2-1

SPRING

€ 3.50

2-2

0944315030
ref: 2-2
E15, E18 E2, F.NO. 1

SPRING

€ 19.50

3

0911110014
ref: 3

BOLT(10X28)

€ 3.50

4

0831022107
ref: 4

NUT

€ 2.50

5

4311036A01
ref: 5

PEDAL,BRAKE

€ 26.50

6

2565249300
ref: 6

RUBBER,PEDAL

€ 5.50

7

4321104701
ref: 7

SPRING,BRAKE PEDAL RETURN

€ 4.00

8

4321204700
ref: 8

WASHER

€ 2.00

9

4325104700
ref: 9

BRACKET,STOP LAMP SWITCH

€ 3.50

10

0411120308
ref: 10

COTTER PIN

€ 1.00

11

0170406188
ref: 11

BOLT

€ 3.00

12

0831012068
ref: 12

NUT

€ 2.50

13

4330036A01
ref: 13

ROD ASSY, REAR BRAKE

€ 13.00

14

0944009004
ref: 14

SPRING

€ 2.00

15

0920911002
ref: 15

PIN(11X18)

€ 2.00

16

0915006009
ref: 16

NUT (6MM)

€ 3.50

17

0832221067
ref: 17

WASHER

€ 2.00

18

0411120158
ref: 18

PIN

€ 1.50

19

4210036A00
ref: 19
OPT

STAND ASSY, REAR

€ 0.00

20

5721102100
ref: 20
OPT

GRIP,L

€ 12.00

STAND - REAR BRAKE

all assemblies
