9 CAM CHAIN

ST400V TEMPTER NK43A

9 cam chain diagram ST400V TEMPTER NK43A

9 CAM CHAIN ST400V TEMPTER NK43A

9 CAM CHAIN ST400V TEMPTER NK43A

prices are in EUR

ref

part #

description

quantity

1

1276024B00
ref: 1
132LE

CHAIN,CAMSHAFT DRIVE

€ 154.00

2

1277124B01
ref: 2

GUIDE,CAM CHAIN

€ 36.50

3

1281124B00
ref: 3

TENSIONER,CAM CHAIN

€ 78.00

4

1281224B00
ref: 4

BOLT,CAM CHAIN TENSIONER

€ 5.50

5

0916808008
ref: 5

GASKET 8.2X14X1 (NAS)

€ 1.00

6

1283024B01
ref: 6

ADJUSTER ASSY,TENSIONER

€ 68.50

7

0910808194
ref: 7

BOLT,STUD

€ 9.50

8

0911906069
ref: 8

BOLT

€ 5.50

9

0833131086
ref: 9

CIRCLIP

€ 2.00
