THROTTLE BODY

ref

part #

description

quantity

1

1340102FA0
ref: 1

BODY ASSY,THROTTLE FR

€ 692.50

1

1340102FB0
ref: 1
E18,E22

BODY ASSY,THROTTLE FR

€ 0.00

2

1355702FA0
ref: 2

PACKING (NAS)

€ 2.50

3

1354202FA0
ref: 3

LEVER ASSY

€ 37.00

4

1337560A00
ref: 4

SPRING

€ 4.00

5

1360242E10
ref: 5

SCREW

€ 3.00

6

1354302FA0
ref: 6

LEVER

€ 18.50

7

9556982140
ref: 7

RING

€ 5.50

8

1360160AT0
ref: 8

SCREW SET,ADJUST

€ 4.50

9

0211204203
ref: 9

SCREW

€ 1.00

10

1354402FA0
ref: 10

LEVER ASSY

€ 21.00

11

1360737010
ref: 11

NUT

€ 2.00

12

0832101087
ref: 12

WASHER,LOCK

€ 2.00

13

1327193011
ref: 13

SPRING

€ 4.50

14

0940106101
ref: 14

CLIP

€ 2.50

15

1327484000
ref: 15

CAP

€ 5.50

16

1327002FA0
ref: 16

ADJUST SCREW ASSY

€ 87.50

17

1340202FA0
ref: 17

BODY ASSY,THROTTLE RR

€ 692.50

17

1340202FB0
ref: 17
E18,E22

BODY ASSY,THROTTLE RR

€ 0.00

18

1360737010
ref: 18

NUT

€ 2.00

19

0832101087
ref: 19

WASHER,LOCK

€ 2.00

20

1354502FA0
ref: 20

LEVER ASSY

€ 17.50

21

1357402FA0
ref: 21

RING

€ 5.50

22

1357302FA0
ref: 22

SPRING

€ 7.00

23

1360202F00
ref: 23

SCREW

€ 2.50

24

0940406432
ref: 24

CLAMP(L:65)

€ 2.50

25

1362702FA0
ref: 25

BRACKET

€ 10.00

26

1360547080
ref: 26

SCREW

€ 7.00

27

1360747070
ref: 27

NUT

€ 4.00

28

0940106101
ref: 28
E2,E4,E24,E25,E34

CLIP

€ 2.50

29

1327484000
ref: 29
E2,E4,E24,E25,E34

CAP

€ 5.50

30

1371502FA0
ref: 30

CHAMBER,VACUUM

€ 23.00

31

1391102FA0
ref: 31

PLATE VACUUM CHAMBER

€ 4.50

32

1391202FA0
ref: 32

BAND,VACUUM CHAMBER

€ 8.50

33

0924810010
ref: 33

PLUG(10X10)

€ 4.00

34

0928060005
ref: 34

O RING(D:2.4,ID:60.5)

€ 3.00

35

1327902FA0
ref: 35

PLATE,IDLE ADJUST

€ 6.00

36

0214206123
ref: 36

SCREW 6X12

€ 2.00

37

1859080C50
ref: 37

SENSOR,MAP

€ 365.50

38

0354105163
ref: 38

SCREW

€ 1.50
