STAND - FOOTREST
TS250 1981 (X) USA (E03)
Stand - footrest diagram TS250 1981 (X) USA (E03)
STAND - FOOTREST TS250 1981 (X) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4231048500
ref: 1
STAND,PROP
€ 137.50
2
0944314017
ref: 2
SPRING
€ 6.50
3
0910010067
ref: 3
BOLT(10X30)
€ 3.50
4
0831022108
ref: 4
08310-00107
NUT
€ 2.50
5
4351030501
ref: 5
HOLDER,FRONT FOOTREST,RIGHT
€ 26.50
6
4352030501
ref: 6
HOLDER,FRONT FOOTREST
€ 0.00
7
4355041102
ref: 7
43550-48501
FOOTREST,FRONT
€ 30.50
8
4356041102
ref: 8
43560-48501
FOOTREST
€ 31.50
9
0920010008
ref: 9
PIN
€ 3.00
10
0411120208
ref: 10
04111-2020A
PIN 20X20
€ 1.50
11
0944815004
ref: 11
SPRING
€ 2.50
12
0110708168
ref: 12
01500-0816B
BOLT
€ 2.00
13
0910008135
ref: 13
09100-08215
BOLT 8X16
€ 3.00
14
0832131088
ref: 14
08321-01087
WASHER,LOCK,8.
€ 2.00
15
4361003001
ref: 15
BAR,FOOTREST RUBBER
€ 5.50
16
4361203001
ref: 16
RUBBER,PILLION FOOTREST
€ 3.50
17
0916019006
ref: 17
09160-19024
WASHER (19.5X32X2)
€ 2.00
18
0920006010
ref: 18
PIN
€ 2.50
19
0411120208
ref: 19
04111-2020A
PIN 20X20
€ 1.50
