AIR CLEANER (REAR)

VS1400GLP INTRUDER 2001 (K1) USA (E03)

Air cleaner (rear) diagram VS1400GLP INTRUDER 2001 (K1) USA (E03)

prices are in EUR

ref

part #

description

quantity

1370038B70
ref: 1

CLEANER ASSY,AIR RR

€ 211.00

1374038B51
ref: 2

CAP,AIR CLEANER RR

€ 29.00

1378138B60
ref: 3

FILTER,AIR RR

€ 11.00

0214205163
ref: 4
02142-0516A

SCREW

€ 2.50

1388138B50
ref: 5

TUBE,AIR CLEANER OUTLET

€ 25.50

1389138B50
ref: 6

TUBE,INLET

€ 21.00

0940282202
ref: 7
09402-82208

CLAMP

€ 7.00

0940258208
ref: 8

CLAMP

€ 5.50

1387011458
ref: 9

TUBE,DRAIN

€ 13.50

0940113409
ref: 10

CLIP

€ 2.50

0150006207
ref: 11

BOLT

€ 2.00

0832101067
ref: 12

WASHER,LOCK

€ 2.50

0916006019
ref: 13

WASHER(6.5X16X1.2)

€ 1.50
