CAM CHAIN
VS1400GLP INTRUDER 2001 (K1) USA (E03)
Cam chain diagram VS1400GLP INTRUDER 2001 (K1) USA (E03)
CAM CHAIN VS1400GLP INTRUDER 2001 (K1) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1276038B00
ref: 1
CHAIN,CAMSHAFT DRIVE
€ 109.50
2
1277138B00
ref: 2
GUIDE,CAM CHAIN
€ 44.50
3
1281138B00
ref: 3
TENSIONER,CAM CHAIN
€ 43.00
4
0910006129
ref: 4
BOLT(6X26)
€ 2.00
5
0821106182
ref: 5
WASHER
€ 2.00
6
0918006184
ref: 6
SPACER(6X11X9)
€ 5.00
7
1283138A00
ref: 7
12831-38A01
ADJUSTER ASSEMBLY,FRONT TENSIONER
€ 70.50
8
0713006203
ref: 8
07130-0620B
BOLT,CRKCASE,R
€ 3.00
9
0713006453
ref: 9
07130-0645B
BOLT
€ 2.50
10
1283238A00
ref: 10
12832-38A01
ADJUSTER ASSEMBLY,REAR TENSIONER
€ 99.00
