Buy Suzuki VS Parts Online


HANDLEBAR (MODEL Y/K1/K2/K3)

VS1400GLP INTRUDER 2001 (K1) USA (E03)

Handlebar (model y/k1/k2/k3) diagram VS1400GLP INTRUDER 2001 (K1) USA (E03)

HANDLEBAR (MODEL Y/K1/K2/K3) VS1400GLP INTRUDER 2001 (K1) USA (E03)
HANDLEBAR (MODEL Y/K1/K2/K3) VS1400GLP INTRUDER 2001 (K1) USA (E03)
HANDLEBAR (MODEL Y/K1/K2/K3) VS1400GLP INTRUDER 2001 (K1) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
5611138E00
ref: 1
HANDLEBAR
5611138E00
€ 163.50
2
5620048831
ref: 2
BALANCER SET,HANDLEBAR
5620048831
€ 58.00
3
0912706019
ref: 3
SCREW(6X110)
0912706019
€ 4.50
4
5627226D01
ref: 4
EXPANDER,HANDLE BALANCER NO.2
5627226D01
€ 5.00
5
5627617D00
ref: 5
SPACER,EXPANDER
5627617D00
€ 2.50
6
0916006121
ref: 6
WASHER(6.5X18X2)
0916006121
€ 10.50
7
0915906024
ref: 7
NUT
0915906024
€ 2.00
8-1
5650038B01
ref: 8-1
MIRROR ASSY,RR VIEW,R
5650038B01
€ 240.50
8-2
5650038B01
ref: 8-2
MIRROR ASSY,RR VIEW,R
5650038B01
€ 240.50
8-3
5650038B01
ref: 8-3
MIRROR ASSY,RR VIEW,R
5650038B01
€ 240.50
9-1
5660038B01
ref: 9-1
MIRROR ASSY,RR VIEW,L
5660038B01
€ 294.00
9-2
5660038B01
ref: 9-2
MIRROR ASSY,RR VIEW,L
5660038B01
€ 294.00
9-3
5660038B01
ref: 9-3
MIRROR ASSY,RR VIEW,L
5660038B01
€ 294.00
10
5830038B30
ref: 10
CABLE ASSY,THROTTLE
5830038B30
€ 93.00
11
0214205087
ref: 11
SCREW
0214205087
€ 2.00
12
5862138B00
ref: 12
CLAMP,THROTTLE CABLE CONNECTOR
€ 6.00
13
0211275123
ref: 13
02112-7512A
SCREW
€ 2.50
14
5840038B01
ref: 14
58400-39B00
CABLE ASSEMBLY,STARTER
5840038B01
€ 34.00
