HANDLE SWITCH (VS1400K5)

VS1400GLP INTRUDER 2004 (K4) USA (E03)

Handle switch (vs1400k5) diagram VS1400GLP INTRUDER 2004 (K4) USA (E03)

HANDLE SWITCH (VS1400K5) VS1400GLP INTRUDER 2004 (K4) USA (E03)

HANDLE SWITCH (VS1400K5) VS1400GLP INTRUDER 2004 (K4) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3720038BJ0
ref: 1

SWITCH ASSY,HANDLE,R

€ 0.00

2

0211205167
ref: 2

SCREW

€ 2.50

3

3740038BJ0
ref: 3

SWITCH ASSY,HANDLE,L

€ 0.00

4

0211205167
ref: 4

SCREW

€ 2.50

5

3756038A00
ref: 5

SWITCH ASSY,CLUTCH

€ 20.00

6

0214203127
ref: 6

SCREW

€ 2.00

7

0940714401
ref: 7

CLAMP

€ 3.00
