Buy Suzuki unknown Parts Online


OIL PUMP

DR-Z125 2012 (L2) USA (E03) DRZ125 DR Z125

Oil pump diagram DR-Z125 2012 (L2) USA (E03) DRZ125 DR Z125

OIL PUMP DR-Z125 2012 (L2) USA (E03) DRZ125 DR Z125
OIL PUMP DR-Z125 2012 (L2) USA (E03) DRZ125 DR Z125
OIL PUMP DR-Z125 2012 (L2) USA (E03) DRZ125 DR Z125
prices are in EUR
ref
part #
description
quantity
1
1640042A01
ref: 1
PUMP ASSY,ENGINE OIL
1640042A01
€ 100.50
2
1633104B00
ref: 2
GEAR,OIL PUMP DRIVEN
1633104B00
€ 24.00
3
0926102008
ref: 3
PIN(2.5X11.8)
0926102008
€ 1.50
4
083321106A
ref: 4
E RING
083321106A
€ 2.00
5
021120625A
ref: 5
SCREW
021120625A
€ 2.00
6
1652005202
ref: 6
STRAINER,ENGINE OIL
1652005202
€ 4.50
7
021127512A
ref: 7
SCREW
021127512A
€ 2.50
8
1652305200
ref: 8
CAP,OIL STRAINER
1652305200
€ 9.00
9
0928060005
ref: 9
O RING(D:2.4,ID:60.5)
0928060005
€ 3.00
10
015470620A
ref: 10
BOLT
015470620A
€ 2.50
11
0924714026
ref: 11
PLUG(14X12)
0924714026
€ 3.50
12
0916814002
ref: 12
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
0916814002
€ 2.50
13
1651025C00
ref: 13
FILTER ASSY,ENGINE OIL
1651025C00
€ 8.50
14
0928013004
ref: 14
O RING(D:1.9,ID:13)
0928013004
€ 2.50
15
1651242A20
ref: 15
CAP,OIL FILTER
1651242A20
€ 21.50
16
0928054001
ref: 16
O RING(D:2.4,ID:52.6)
0928054001
€ 4.00
17
0944018002
ref: 17
SPRING
0944018002
€ 1.50
18
0910806123
ref: 18
BOLT,STUD
0910806123
€ 3.00
19
0910806108
ref: 19
BOLT,STUD
0910806108
€ 4.50
20
083131006A
ref: 20
NUT
083131006A
€ 1.50
