CAM CHAIN

RM-Z250 2008 (K8) USA (E03) RMZ250 RM Z250

Cam chain diagram RM-Z250 2008 (K8) USA (E03) RMZ250 RM Z250

prices are in EUR

ref

part #

description

quantity

1276010H00
ref: 1

CHAIN,CAMSHAFT DRIVE

€ 51.00

1277110H00
ref: 2

GUIDE,CAM CHAIN NO.1

€ 28.00

1278235G00
ref: 3

GUIDE,CAM CHAIN NO.2

€ 9.00

1277310H00
ref: 4

RETAINER,CAM CHAIN GUIDE NO.1

€ 5.00

071200610B
ref: 5

BOLT

€ 2.00

1281110H00
ref: 6

TENSIONER,CAM CHAIN

€ 44.50

1281235G00
ref: 7

SPACER,CAM CHAIN TENSIONER

€ 7.50

071300616B
ref: 8

BOLT

€ 3.00

1283010H00
ref: 9

ADJUSTER ASSY,TENSIONER

€ 91.00

1283110H00
ref: 10

SPRING,ADJUSTER

€ 5.00

1283610H00
ref: 11

BAR,ADJUSTER

€ 5.50

1283310H00
ref: 12

PLUG,ADJUSTER

€ 14.50

1283724F10
ref: 13

GASKET,TENSIONER ADJUSTER (NAS)

€ 4.00

0928019001
ref: 14

O RING(D:1.9,ID:18.8)

€ 1.50

071300625B
ref: 15

BOLT

€ 3.00
