HANDLE SWITCH

DL1000 VSTROM 2009 (K9) USA (E03)

Handle switch diagram DL1000 VSTROM 2009 (K9) USA (E03)

HANDLE SWITCH DL1000 VSTROM 2009 (K9) USA (E03)

HANDLE SWITCH DL1000 VSTROM 2009 (K9) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3720006G80
ref: 1

SWITCH ASSY,HANDLE,R

€ 170.50

2

021120545B
ref: 2

SCREW

€ 4.00

3

3740006G10
ref: 3

SWITCH ASSY,HANDLE,L

€ 228.00

4

021120530B
ref: 4

SCREW

€ 1.50

5

021120540B
ref: 5

SCREW

€ 2.00

6

0940712402
ref: 6

CLAMP(L:120)

€ 3.00
