REAR FENDER

DR400 1980 (T) USA (E03)

Rear fender diagram DR400 1980 (T) USA (E03)

prices are in EUR

ref

part #

description

quantity

631113720010V
ref: 1
63111-37202-10V

FENDER,REAR

€ 0.00

0110708258
ref: 2
01500-08257

BOLT

€ 2.50

0916008010
ref: 3
09160-08054

WASHER (8.2X20X1.6)

€ 1.50

0832131088
ref: 4
08321-01087

WASHER,LOCK,8.

€ 2.00

0831012088
ref: 5
08310-00087

NUT

€ 2.00

0110708208
ref: 6
01500-08207

BOLT

€ 3.00

0916008010
ref: 7
09160-08054

WASHER (8.2X20X1.6)

€ 1.50

0832121088
ref: 8
08321-01087

LOCK WASHER

€ 2.00

6341137200
ref: 9

MUD GUARD,REAR FENDER

€ 21.00

0940711301
ref: 10
09407-18301

CLAMP L:110

€ 6.00
