prices are in EUR
ref
part #
description
quantity
1-1
COVER,CLUTCH (BLUE)
1-2
COVER,CLUTCH (ORANGE)
1-3
COVER,CLUTCH (SILVER)
2
PLUG
3-1
GASKET,CLUTCH COVER (NAS)
3-2
GASKET,CLUTCH COVER (NA)
4
PIN
6
BOLT 6X50
7
BOLT
9
BOLT 6X30
10
BOLT 6X25
11
PLUG(14X12)
12
GASKET(14X19.2X2) (NAS)
14
O RING(D:1.2,ID:4)
15-1
GAUGE,OIL LEVEL
15-2
GAUGE,OIL LEVEL
16
O RING(D:3.1,ID:16.8)
17-1
COVER,MAGNETO (BLUE)
17-2
COVER,MAGNETO (ORANGE)
17-3
COVER,MAGNETO (SILVER)
18-1
GASKET,MAGNETO COVER (MCA)
18-2
GASKET,MAGNETO COVER (NA)
19
PIN
20
BOLT
21
BOLT 6X35
22
BOLT 6X25
23
GASKET(5.8X13X1.2) (NAS)
24
PLUG
25
O RING(D:3.1,ID:32.7)
26-1
COVER,ENGINE SPROCKET (BLUE)
26-2
COVER,ENGINE SPROCKET (ORANGE)
26-3
COVER,ENGINE SPROCKET (SILVER)
27
BOLT 6X30
28
BOLT 6X25
31-1
COVER,GEARSHIF
31-2
COVER,GEAR SHIFT (ORANGE)
31-3
COVER,GEAR SHIFT (SILVER)
32-1
GASKET,GEAR SHIFT COVER
32-2
GASKET,GEAR SHIFT COVER (NA)
33
PIN
34
BOLT 6X30
35
BOLT 6X25
36
BOLT
37
PLATE,FR CHAIN GUIDE
