prices are in EUR
ref
part #
description
quantity
1
NO PRODUCT DESCRIPTION AVAILABLE
2
SEAT, STEP TYPE (WITH BAND)
3
SEAT ASSEMBLY
5
CUSHION
6
BOLT
7
WASHER
8
LOCK WASHER
9
END,SHEET HANDLE
11
HANDLE,PILLION RIDER
12
CUSHION
13
BOLT
14
WASHER
15
LOCK WASHER
16
END,SHEET HANDLE
17-1
PLATE, SEAT LOWER (RED)
17-2
PLATE, SEAT LOWER (BLUE)
17-3
PLATE, SEAT LOWER (BLACK)
17-4
NO PRODUCT DESCRIPTION AVAILABLE
18
NUT
19
PIN
20
PIN
21
CUSHION
22
CUSHION
23
STRIKER,SEAT LOCK
24
NUT
25
LOCK WASHER
26
WASHER
27
WASHER (6.5X20X1.2)
28
COVER, SEAT TAIL (RED)
30-1
NO PRODUCT DESCRIPTION AVAILABLE
30-2
COVER, SEAT TAIL (BLUE)
32
COVER, SEAT TAIL (BLACK)
35
CLIP,SEAT TAIL COVER M
36
WASHER
37
NUT 6MM
38
LOCK ASSY,SEAT
40
LOCK WASHER
41
SPRING,HELMET HOLDER
42
SCREW
43
HOLDER,TOOL
44
WASHER
45
NUT
46
BAND
49
BOLT
50
WASHER
