CLUTCH

GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37

Clutch diagram GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37

CLUTCH GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37
CLUTCH GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37
CLUTCH GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37
prices are in EUR
ref
part #
description
quantity
1-1
2120026830
ref: 1-1
MODEL S/T/V
GEAR ASSEMBLY,PRIMARY DRIVE
€ 426.00
1-2
2120026832
ref: 1-2
MODEL W
GEAR ASSEMBLY,PRIMARY DRIVE
2120026832
€ 426.00
2-1
2272117D01
ref: 2-1
MODEL S/T/V
GEAR,GENERATOR DRIVE,N
€ 140.00
2-2
2272117D02
ref: 2-2
MODEL W
GEAR,GENERATOR DRIVE
€ 140.00
3-1
0916025067
ref: 3-1
MODEL S/T
WASHER(25X54X2.5)
0916025067
€ 9.00
3-2
0916025037
ref: 3-2
MODEL V/W
WASHER(25X54X2.5)
0916025037
€ 9.00
4
0926335017
ref: 4
BEARING(35X40X35.8)
0926335017
€ 36.50
5
2141027A02
ref: 5
HUB,CLUTCH SLEEVE
2141027A02
€ 134.50
6
2144137400
ref: 6
PLATE,CLUTCH DRIVE (NAS)
2144137400
€ 20.50
7
2145105A00
ref: 7
PLATE,CLUTCH DRIVEN (NAS)
2145105A00
€ 9.00
8
2146227A00
ref: 8
DISC,CLUTCH PRESSURE
2146227A00
€ 37.00
9-1
0911606168
ref: 9-1
MODEL S/T/V <-09116-
BOLT(6X16)
0911606168
€ 2.50
9-2
0911606167
ref: 9-2
MODEL W
BOLT(6X20)
0911606167
€ 2.00
10
0914022008
ref: 10
NUT
0914022008
€ 4.50
11
0916025056
ref: 11
WASHER(25X50X2.5)
0916025056
€ 9.50
12
0916422007
ref: 12
WASHER
0916422007
€ 5.00
13-1
0916725024
ref: 13-1
MODEL S/T
WASHER,LOCK
0916725024
€ 3.00
13-2
0918122251
ref: 13-2
MODEL V/W
SHIM(22X36X1)
0918122251
€ 3.50
14
0916922005
ref: 14
~GN77A-102859 ~GN77B
WASHER
0916922005
€ 3.00
15-1
0944019020
ref: 15-1
MODEL S
SPRING
0944019020
€ 4.50
15-2
0944020020
ref: 15-2
MODEL T/V/W
SPRING
0944020020
€ 8.50
16
2311020C00
ref: 16
ROD,CLUTCH PUSH,R
2311020C00
€ 23.00
17
2311108A00
ref: 17
ROD,CLUTCH PUSH,L
2311108A00
€ 15.50
18
2312127A00
ref: 18
PIECE,CLUTCH PUSH
2312127A00
€ 21.50
19
2320031300
ref: 19
SCREW ASSY,CLUTCH RELEASE
2320031300
€ 104.50
20
0913406010
ref: 20
SCREW(6X25)
0913406010
€ 3.00
21
0831000067
ref: 21
NUT
0831000067
€ 2.50
22
0916015045
ref: 22
WASHER(15.5X28X1)
0916015045
€ 4.00
23
0926315003
ref: 23
BEARING(15X28X2)
0926315003
€ 7.00
24
0928506015
ref: 24
SEAL,OIL(6X34X5.5)
0928506015
€ 8.50
25
0944307038
ref: 25
SPRING
0944307038
€ 4.00
26
0155006163
ref: 26
BOLT
0155006163
€ 2.50
