TAIL LAMP

GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37

Tail lamp diagram GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37

TAIL LAMP GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37

TAIL LAMP GSF600 1999 (X) (E02 E04 E17 E18 E22 E25 E34) / P37

prices are in EUR

ref

part #

description

quantity

1

3571026E00
ref: 1

LAMP ASSY,RR COMBINATION

€ 170.00

2

0321104123
ref: 2

SCREW

€ 1.50

3

3571826E00
ref: 3

SOCKET & CORD

€ 38.00

4

0947112083
ref: 4

BULB(12V21/5W)

€ 6.00

5

3573648B21
ref: 5

PLATE NO.2

€ 16.50

6

3576548B21
ref: 6

CUSHION

€ 10.50

7

0351114123
ref: 7

TPG SCREW

€ 2.50

8

3591026E00
ref: 8

LAMP ASSY,LICENSE PLATE

€ 193.50

9

3591717C10
ref: 9

COVER,LENS

€ 72.00

10

3591238A20
ref: 10

LENS

€ 13.00

11

0947112140
ref: 11

BULB(12V5W,BF150-40160A)

€ 4.00

12

3576124B31
ref: 12

CUSHION

€ 9.00

13

3576624B30
ref: 13

SPACER

€ 2.00

14

0914004006
ref: 14

NUT

€ 4.00

15

3592700A10
ref: 15
MODEL S/T

BRACKET,LICENSE PLATE

€ 6.00

15A

3592727E00
ref: 15A
MODEL V/W

BRACKET,LICENSE PLATE

€ 10.00

16

0214206123
ref: 16

SCREW 6X12

€ 2.00

17

0916006088
ref: 17

WASHER(6.5X20X1.6)

€ 2.00

18

0831000063
ref: 18

NUT 6MM

€ 2.00

19

0932106030
ref: 19

CUSHION

€ 3.00

20

3595043431
ref: 20
E18

REFLEX REFLECTOR,FR SIDE

€ 12.00

21

0831000053
ref: 21
E18

NUT

€ 2.50
