AIR CLEANER

GSX1100G 1992 (N) USA (E03)

Air cleaner diagram GSX1100G 1992 (N) USA (E03)

AIR CLEANER GSX1100G 1992 (N) USA (E03)

AIR CLEANER GSX1100G 1992 (N) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1370026D00
ref: 1

CLEANER ASSEMBLY,AIR

€ 268.00

2

1388101D00
ref: 2
13881-01D01

TUBE,OUTLET

€ 20.00

3

1378026D00
ref: 3

FILTER ASSY

€ 63.00

4

0214205124
ref: 4
02142-0512A

SCREW, FRONT & REAR

€ 1.50

5

0940268208
ref: 5

CLAMP

€ 6.00

6

1385326D00
ref: 6

TUBE,BREATHER

€ 14.50

7

1382448B10
ref: 7
09401-16401

CLIP

€ 3.00

8

1387026D00
ref: 8
13870-21308

DRAIN TUBE

€ 16.50

9

1382400A00
ref: 9
09401-13409

CLIP

€ 2.50

10

0117706166
ref: 10
01580-0616A

BOLT

€ 2.00

11

0940714403
ref: 11

CLAMP(L:125)

€ 2.50
