OIL COOLER

GSX1100G 1994 (R) (E02 E04 E18 E22 E24 E25)

Oil cooler diagram GSX1100G 1994 (R) (E02 E04 E18 E22 E24 E25)

OIL COOLER GSX1100G 1994 (R) (E02 E04 E18 E22 E24 E25)
OIL COOLER GSX1100G 1994 (R) (E02 E04 E18 E22 E24 E25)
OIL COOLER GSX1100G 1994 (R) (E02 E04 E18 E22 E24 E25)
prices are in EUR
ref
part #
description
quantity
1
1660026D01
ref: 1
16600-26D00
COOLER,OIL
€ 1,173.50
2
0911808131
ref: 2
BOLT(8X40)
0911808131
€ 3.50
3
0918008124
ref: 3
SPACER (8.8X12X24.5)
€ 7.00
4
1662927A01
ref: 4
CUSHION,OIL COOLER NO.1
1662927A01
€ 4.00
5
1662827A00
ref: 5
CUSHION,OIL COOLER NO.2
1662827A00
€ 3.00
6
1646026D00
ref: 6
HOSE,OIL COOLER,L
€ 192.50
7
1647026D00
ref: 7
HOSE COMP,OIL COOLER,RIGHT
€ 206.50
8-1
0711006165
ref: 8-1
MODEL M/N/P
BOLT
0711006165
€ 3.00
8-2
0713006167
ref: 8-2
MODEL R
BOLT
0713006167
€ 3.00
9
0928012008
ref: 9
O RING(D:2.4,ID:12.3)
0928012008
€ 3.00
10
0936016002
ref: 10
BOLT UNION
0936016002
€ 12.00
11
0916816003
ref: 11
GASKET(16X22X2) (NAS)
0916816003
€ 2.00
12
0940725401
ref: 12
CLAMP(L:235)
0940725401
€ 4.00
13
1665026D01
ref: 13
NET,OIL COOLER
€ 64.00
14-1
0214205084
ref: 14-1
MODEL M/N/P
SCREW
€ 2.00
14-2
0214205083
ref: 14-2
MODEL R
SCREW
0214205083
€ 2.00
15-1
0914805023
ref: 15-1
MODEL M/N/P
NUT
0914805023
€ 1.50
15-2
0914805021
ref: 15-2
MODEL R
NUT
0914805021
€ 1.50
16
1647926D00
ref: 16
MODEL M
CLAMP,OIL HOSE
€ 2.50
16A
1647926D10
ref: 16A
MODEL N/P/R
CLAMP,OIL HOSE
€ 5.00
17-1
0713006205
ref: 17-1
MODEL M/P
BOLT
€ 3.00
17-2
0713006205
ref: 17-2
MODEL N
BOLT
€ 3.00
17-3
0713006167
ref: 17-3
MODEL R
BOLT
0713006167
€ 3.00
