REAR SWINGING ARM

GSX500E 1984 (E) GENERAL EXPORT (E01)

Rear swinging arm diagram GSX500E 1984 (E) GENERAL EXPORT (E01)

REAR SWINGING ARM GSX500E 1984 (E) GENERAL EXPORT (E01)
REAR SWINGING ARM GSX500E 1984 (E) GENERAL EXPORT (E01)
REAR SWINGING ARM GSX500E 1984 (E) GENERAL EXPORT (E01)
prices are in EUR
ref
part #
description
quantity
1
610004340013L
ref: 1
ARM,REAR SWING
€ 209.50
2
0926325024
ref: 2
BEARING(25X33X30)
0926325024
€ 31.50
3
6125143400
ref: 3
SPACER,RR SWGARM PIVOT
6125143400
€ 22.00
4
0821116381
ref: 4
WASHER
0821116381
€ 2.50
5
6126249000
ref: 5
COVER,RR SWGARM DUST SEAL
6126249000
€ 17.50
6
6121143400
ref: 6
SHAFT,REAR SWING ARM
6121143400
€ 27.50
7
0832211148
ref: 7
WASHER
0832211148
€ 2.00
8
0915914013
ref: 8
NUT
0915914013
€ 8.50
9
6122243400
ref: 9
CAP,SWINGINGARM PIVOT
6122243400
€ 4.00
10
6127343401
ref: 10
BUFFER,DEFENSE
6127343401
€ 27.00
11
6431033400291
ref: 11
TORQUE LINK,REAR
6431033400291
€ 17.50
12
0911110011
ref: 12
BOLT
0911110011
€ 8.00
13
0910110031
ref: 13
BOLT
€ 4.00
14
0832211105
ref: 14
WASHER
€ 2.50
15
0831441108
ref: 15
NUT
0831441108
€ 2.50
16
0411120208
ref: 16
PIN 20X20
0411120208
€ 1.50
17
6131143400
ref: 17
CASE,CHAIN
6131143400
€ 43.50
18
0110706105
ref: 18
BOLT
€ 2.00
19
0916906026
ref: 19
WASHER
0916906026
€ 2.00
