CRANKCASE COVER
GSXR1000 2008 (K8) USA (E03)
Crankcase cover diagram GSXR1000 2008 (K8) USA (E03)
CRANKCASE COVER GSXR1000 2008 (K8) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1134041G10
ref: 1
COVER,CLUTCH
€ 261.00
2
1197133210
ref: 2
LENS,OIL LEVEL CHECK
€ 13.50
3
1134241G10
ref: 3
CAP,CLUTCH RELEASE ADJUST
€ 20.00
4
0928054001
ref: 4
O RING(D:2.4,ID:52.6)
€ 4.00
5
1148240F00
ref: 5
GASKET,CL COVE (NAS)
€ 15.50
6
0421109189
ref: 6
PIN
€ 2.00
7
0916806023
ref: 7
GASKET(5.8X13X1.2) (NAS)
€ 2.00
8
015470630A
ref: 8
BOLT
€ 2.50
9
1197125D00
ref: 9
PLUG,ENGINE OIL FILLER
€ 5.50
10
0928017003
ref: 10
O RING(D:3.1,ID:16.8)
€ 2.00
11
1138135F10
ref: 11
COVER,STARTER CLUTCH
€ 136.00
12
1149133E02
ref: 12
GASKET,STARTER CLUTCH COVER
€ 8.00
13
0421109149
ref: 13
PIN
€ 2.00
14
015470625A
ref: 14
BOLT
€ 2.50
15
015470635A
ref: 15
BOLT
€ 3.00
16
0916806023
ref: 16
GASKET(5.8X13X1.2) (NAS)
€ 2.00
17
0925936021
ref: 17
PLUG
€ 11.00
18
0928033004
ref: 18
O RING(D:3.1,ID:32.7)
€ 2.50
19
1138233E10
ref: 19
CAP,STRAINER IDLE GEAR
€ 60.50
20
1149233E00
ref: 20
GASKET,START IDLE GEAR CAP (NAS)
€ 6.50
21
015470655A
ref: 21
BOLT
€ 2.50
22
0916806023
ref: 22
GASKET(5.8X13X1.2) (NAS)
€ 2.00
23
0421109149
ref: 23
PIN
€ 2.00
24
015470625A
ref: 24
BOLT
€ 2.50
25
015470635A
ref: 25
BOLT
€ 3.00
26
1135141G10
ref: 26
COVER,MAGNETO
€ 172.00
27
1148318G00
ref: 27
GASKET,MAGNETO COVER (NAS)
€ 10.50
28
0421109149
ref: 28
PIN
€ 2.00
29
015470630A
ref: 29
BOLT
€ 2.50
30
015470640A
ref: 30
BOLT
€ 2.50
31
0916806023
ref: 31
GASKET(5.8X13X1.2) (NAS)
€ 2.00
32
1136121H00
ref: 32
COVER,ENGINE SPROCKET
€ 175.00
33
0421109129
ref: 33
PIN
€ 2.00
34
1136221H00
ref: 34
DAMPER,ENGINE SPROCKET COVER
€ 27.50
35
1136312H00
ref: 35
PLATE,ENGINE SPROCKET COVER
€ 9.50
36
0910306172
ref: 36
BOLT(6X12)
€ 2.00
37
015470655A
ref: 37
BOLT
€ 2.50
38
015470665A
ref: 38
BOLT
€ 2.50
