GENERATOR

GSXR1000 2008 (K8) USA (E03)

Generator diagram GSXR1000 2008 (K8) USA (E03)

GENERATOR GSXR1000 2008 (K8) USA (E03)

GENERATOR GSXR1000 2008 (K8) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3140141G10
ref: 1

STARTER ASSY

€ 473.00

2

3140241G10
ref: 2

ROTOR ASSY

€ 189.50

3

3237133E00
ref: 3

CLAMP,MAGNETO LEAD

€ 3.50

4

0910312005
ref: 4

BOLT(12X23)

€ 5.50

5

071300612A
ref: 5

BOLT

€ 2.50

6

0910606122
ref: 6

BOLT(6X30)

€ 2.50
