FUEL PUMP

GSXR1000 2008 (K8) USA (E03)

Fuel pump diagram GSXR1000 2008 (K8) USA (E03)

FUEL PUMP GSXR1000 2008 (K8) USA (E03)

FUEL PUMP GSXR1000 2008 (K8) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1510021H00
ref: 1

PUMP ASSY,FUEL

€ 857.00

2

1511127G00
ref: 2

CUP

€ 25.00

3

1511205H00
ref: 3

JOINT

€ 17.00

4

1511305H00
ref: 4

O RING

€ 17.00

5

1511335F00
ref: 5

O RING

€ 7.50

6

1518121H00
ref: 6

BRACKET,GAUGE

€ 21.00

7

1511610F00
ref: 7

SCREW

€ 3.50

8

1542005H00
ref: 8

STRAINER

€ 20.50

9

1561027G00
ref: 9

REGULATOR

€ 165.50

10

1511427G00
ref: 10

WIRE,EARTH

€ 21.00

11

1511527G00
ref: 11

WIRE,LEAD

€ 23.00

12

3481021H00
ref: 12

GAUGE ASSY,FUEL LEVEL SENDER

€ 195.00

13

1511606G10
ref: 13

SCREW

€ 6.50

14

1520135F00
ref: 14

O RING,FUEL PUMP

€ 26.00

15

071200612A
ref: 15

BOLT

€ 3.50

16

1581015H00
ref: 16
15810-15H01

HOSE COMP,FUEL

€ 63.50

17

1581535F00
ref: 17

RETAINER

€ 6.50
