FRONT FENDER

GSXR1000 2008 (K8) USA (E03)

Front fender diagram GSXR1000 2008 (K8) USA (E03)

FRONT FENDER GSXR1000 2008 (K8) USA (E03)

FRONT FENDER GSXR1000 2008 (K8) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

5310041G00019
ref: 1-1

FENDER ASSY,FR(BLACK)

€ 217.50

1-2

5310041G00YBD
ref: 1-2

FENDER ASSY,FR(WHITE)

€ 217.50

1-3

5310041G00019
ref: 1-3

FENDER ASSY,FR(BLACK)

€ 217.50

1-4

5310041G00YRC
ref: 1-4

FENDER,FR

€ 217.50

2

0913906144
ref: 2

SCREW(6X12)

€ 3.00

3

0913906171
ref: 3

SCREW(6X16)

€ 3.00
