CHAIN CASE
PE175 1983 (D) USA (E03)
Chain case diagram PE175 1983 (D) USA (E03)
CHAIN CASE PE175 1983 (D) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
6131140504
ref: 1
CASE,CHAIN
€ 43.00
2
0110706168
ref: 2
01500-06167
BOLT, UPPER
€ 3.00
3
0832121068
ref: 3
08321-01067
LOCK WASHER
€ 2.50
4
0916006028
ref: 4
WASHER(6.5X18X1)
€ 1.50
5
0110706128
ref: 5
01500-06127
BOLT
€ 2.00
6
0832121068
ref: 6
08321-01067
LOCK WASHER
€ 2.50
7
0916906010
ref: 7
WASHER
€ 3.00
8
6132140501
ref: 8
RUBBER,CHAIN CASE,LOWER
€ 19.00
9
0918006032
ref: 9
09180-06246
SPACER (6.1X8X5.2)
€ 2.50
10
0916006028
ref: 10
WASHER(6.5X18X1)
€ 1.50
11
0832121068
ref: 11
08321-01067
LOCK WASHER
€ 2.50
12
0211206128
ref: 12
02112-06127
SCREW 6X12
€ 2.00
