ELECTRICAL

ref

part #

description

quantity

2-1

0940714301
ref: 2-1

CLAMP

€ 6.00

2-2

0940718301
ref: 2-2

CLAMP

€ 6.00

3

0940712402
ref: 3

CLAMP(L:120)

€ 3.00

4

3280016A00
ref: 4

RECTIFIER ASSY

€ 10.50

5

0211205207
ref: 5

SCREW

€ 3.00

6

0832101057
ref: 6

WASHER,LOCK

€ 2.00

7

0832201057
ref: 7

WASHER

€ 2.50

8

3341043011
ref: 8

COIL ASSY,IGNITION

€ 89.50

9

0211206207
ref: 9

SCREW

€ 2.00

10

0832101067
ref: 10

WASHER,LOCK

€ 2.50

11

3674015011
ref: 11

CASE ASSY,FUSE

€ 11.00

12

0948115001
ref: 12

FUSE(15A)

€ 3.00

14

3711025319
ref: 14

SWITCH ASSY,IGNITION

€ 60.00

16

3761053011
ref: 16

SWITCH ASSY,BRAKE LAMP

€ 34.50

17

0944306019
ref: 17

SPRING

€ 3.50

18

4325132400
ref: 18

BRACKET,STOP LAMP SWITCH

€ 8.50

19

0150006107
ref: 19

BOLT

€ 2.00

20

0832201067
ref: 20

WASHER

€ 2.00

21

0832101067
ref: 21

WASHER,LOCK

€ 2.50

22

3850032472
ref: 22

HORN ASSEMBLY

€ 32.50

23

0150006107
ref: 23

BOLT

€ 2.00

24

3651032412
ref: 24

RESISTOR ASSY,MAGNETO

€ 46.50

all assemblies
