MUFFLER
SP370 1978 1979 (C) (N) USA (E03)
Muffler diagram SP370 1978 1979 (C) (N) USA (E03)
MUFFLER SP370 1978 1979 (C) (N) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1415032400
ref: 1
PIPE,EXHAUST
€ 74.50
2
1418101D00
ref: 2
GASKET,EXHAUST PIPE (NAS)
€ 8.00
3
0150006307
ref: 3
BOLT
€ 2.50
4
0832101087
ref: 4
WASHER,LOCK
€ 2.00
5
1418632400
ref: 5
COVER,EXHAUST PIPE
€ 34.50
6
0211205107
ref: 6
SCREW
€ 2.00
7
0916806105
ref: 7
GASKET(6.2X12X1.5) (NAS)
€ 2.00
8
0832201057
ref: 8
WASHER
€ 2.50
9
0832101057
ref: 9
WASHER,LOCK
€ 2.00
10
1431032400H01
ref: 10
MUFFLER ASSEMBLY,FIRST
€ 149.00
11
1477138200H17
ref: 11
CONNECTOR,MUFFLER
€ 56.50
12
1446932400
ref: 12
CLAMP,MUFFLER CONNECTOR
€ 9.00
13
0150008353
ref: 13
BOLT
€ 3.50
14
0832201087
ref: 14
WASHER
€ 2.00
15
0150008307
ref: 15
BOLT
€ 2.50
16
0916008135
ref: 16
WASHER(8.5X28X1.6)
€ 2.00
17
0832101087
ref: 17
WASHER,LOCK
€ 2.00
19
0932013007
ref: 19
CUSHION
€ 4.50
20
0918008076
ref: 20
SPACER (8.6X13.8X13)
€ 2.50
21
0910008083
ref: 21
BOLT(8X27)
€ 3.50
22
0916008135
ref: 22
WASHER(8.5X28X1.6)
€ 2.00
23
0832101087
ref: 23
WASHER,LOCK
€ 2.00
24
0932014009
ref: 24
CUSHION
€ 2.50
25
0918008076
ref: 25
SPACER (8.6X13.8X13)
€ 2.50
