prices are in EUR
ref
part #
description
quantity
1-1
SHAFT,COUNTER (NT:12)
1-2
SHAFT,COUNTER (NT:12)
2
GEAR,2ND DRIVE(NT:15)
3-1
GEAR,THIRD & FOURTH DRIVE,N
3-2
GEAR,3RD & 4TH DRIVE(NT:18/27)
4
GEAR,FIFTH DRIVE (NT:23)
5
BUSHING,FIFTH DRIVE GEAR
6
GEAR,SIXTH DRIVE (NT:24)
7
SHIM(22X30X1)
8
BEARING 20X47X14
9
BEARING(25X62X17)
10
O RING(D:1.9,ID:16.6)
12
CIRCLIP
13
SHAFT,DRIVE
14-1
GEAR,FIRST DRIVEN (NT:32)
14-2
GEAR,1ST DRIVEN(NT:32)
15
GEAR,SECOND DRIVEN (NT:29)
15A
GEAR,SECOND DRIVEN (NT:29)
16
BUSH,2ND DRIVEN GEAR
17-1
GEAR,THIRD DRIVEN (NT:27)
17-2
GEAR,THIRD DRIVEN (NT:27)
18
BUSH
19
BUSH
20
GEAR,FOURTH DRIVEN (NT:27)
21-1
GEAR,FIFTH DRIVEN (NT:25)
21-2
GEAR,FIFTH DRIVEN (NT:25)
22-1
GEAR,SIXTH DRIVEN (NT:24)
22-2
GEAR,SIXTH DRIVEN (NT:24)
23
WASHER(27X36X1)
24
WASHER,LOCK
25
SHIM(20X34X1)
26
SHIM(22X34X1)
27
BEARING(20X52X15)
28
BEARING(28X68X18)
28
BEARING(28X68X18)
28A
BEARING(28X68X20)
28A
BEARING(28X68X20)
29-1
SEAL,OIL(38X52X8)
29-1
SEAL,OIL(38X52X8)
29-2
SEAL,OIL(38X52X8)
29-2
SEAL,OIL(38X52X8)
30
BUSH
31
CIRCLIP
32
CIRCLIP
33
CIRCLIP
34
RETAINER
35
RETAINER,DRIVE SHAFT OIL SEAL
35A
RETAINER,DRIVESHAFT O
36
BOLT
37
SCREW
38
RETAINER,DRIVE SHAFT BEARING
39
SCREW(6X12)
40
SPROCKET,ENGINE (NT:17)
41-1
SPACER,ENGINE SPROCKET
41-2
SPACER,ENGINE SPROCKET
42
CHAIN ASSEMBLY RK50GSVZ1.1
43
NUT
44
SHIM(25X40X1.5)
45
O RING(D:2.4,ID:23.7)
