KICK STARTER
TS125XU 1985 (F) UNITED KINGDOM (E02)
Kick starter diagram TS125XU 1985 (F) UNITED KINGDOM (E02)
KICK STARTER TS125XU 1985 (F) UNITED KINGDOM (E02)
×
prices are in EUR
ref
part #
description
quantity
1
2621101A00
ref: 1
SHAFT, KICK STARTER
€ 45.50
2
2622146000
ref: 2
GUIDE,KICK STARTER SFT SPRING
€ 5.00
3
0833131169
ref: 3
CIRCLIP,16MM
€ 2.00
4
0944841003
ref: 4
SPRING
€ 17.00
5
2623714500
ref: 5
BOLT,KICK SHAFT SPRING
€ 3.50
6
2623138201
ref: 6
STARTER,KICK
€ 25.50
7
0944032006
ref: 7
SPRING
€ 1.50
8
0821117341
ref: 8
WASHER
€ 2.00
9
0928320031
ref: 9
SEAL,OIL(20X27X5)
€ 5.00
10
2623238200
ref: 10
GUIDE,KICK STARTER
€ 4.00
11
2623332400
ref: 11
STOPPER,KICK STARTER
€ 3.00
12
0910008166
ref: 12
BOLT(8X20)
€ 0.00
13
2624001A01
ref: 13
GEAR, DRIVE (NT:27/14)
€ 77.00
14
0821120281
ref: 14
WASHER,THRUST
€ 2.50
15
0916420004
ref: 15
WASHER
€ 5.00
16-1
2630001A01
ref: 16-1
MODEL E/F
LEVER ASSY, KICK STARTER
€ 135.50
16-2
2630001A03
ref: 16-2
MODEL G
LEVER ASSY, KICK STARTER
€ 135.50
17
0910608050
ref: 17
BOLT 8X14
€ 7.00
18
2643101A00
ref: 18
GEAR, TACHO. DRIVEN (NT:11)
€ 16.50
19
2644148700
ref: 19
SLEEVE,TACHOMETER DRIVE GEAR
€ 14.00
20
0916008003
ref: 20
WASHER(8X13.7X1)
€ 2.00
21
0928010001
ref: 21
O RING(D:1.3,ID:9.6)
€ 2.00
22
0913506002
ref: 22
BOLT
€ 2.50
23
0916806004
ref: 23
GASKET(6.2X11X1).2 (NAS)
€ 1.50
