Buy Suzuki VL Parts Online


FRONT CALIPER

VL1500T BOULEVARD C90 2008 (K8) USA (E03)

Front caliper diagram VL1500T BOULEVARD C90 2008 (K8) USA (E03)

FRONT CALIPER VL1500T BOULEVARD C90 2008 (K8) USA (E03)
FRONT CALIPER VL1500T BOULEVARD C90 2008 (K8) USA (E03)
FRONT CALIPER VL1500T BOULEVARD C90 2008 (K8) USA (E03)
prices are in EUR
ref
part #
description
quantity
1-1
5910033DD0999
ref: 1-1
CALIPER ASSY,FR,R
5910033DD0999
€ 518.00
1-2
5930033DD0999
ref: 1-2
CALIPER ASSY,FR,L
€ 386.00
2
5930033831
ref: 2
PISTON SET
5930033831
€ 65.50
3
5930033841
ref: 3
SEAL SET,PISTON
5930033841
€ 26.50
4-1
5911533D00
ref: 4-1
SPRING,PAD,R
5911533D00
€ 12.00
4-2
5931533D00
ref: 4-2
SPRING,PAD,L
5931533D00
€ 11.50
5
5911244B00
ref: 5
BOOT,AXLE
5911244B00
€ 8.00
6
5914144B01
ref: 6
PIN,PAD
5914144B01
€ 8.00
7
5931336500
ref: 7
INSULATOR,AXLE
5931336500
€ 5.50
8
6914245000
ref: 8
CLIP,PAD PIN
6914245000
€ 4.50
9-1
5915033D01
ref: 9-1
CARRIER,CALIPER,R
5915033D01
€ 70.00
9-2
5935033D01
ref: 9-2
CARRIER,CALIPER,L
5935033D01
€ 70.00
10
5911633D00
ref: 10
GUIDE,PAD
5911633D00
€ 6.50
11
5912118410
ref: 11
BLEEDER
5912118410
€ 8.00
12
5515666310
ref: 12
CAP,BLEEDER PLUG
5515666310
€ 6.00
13-1
5910233880
ref: 13-1
PAD & SHIM SET (NAS)
5910233880
€ 65.50
13-2
5930233870
ref: 13-2
PAD & SHIM SET (NAS)
5930233870
€ 65.50
14
5917133D00
ref: 14
SHIM,PAD
5917133D00
€ 10.00
15
5917233D00
ref: 15
SHIM,PAD NO.2
5917233D00
€ 10.50
16
0910610038
ref: 16
BOLT(10X33)
0910610038
€ 4.50
17
0925008014
ref: 17
CAP(OD:12)
0925008014
€ 3.50
