FUEL TANK

VS1400 BOULEVARD S83 2009 (K9) CALIFORNIA (E33)

Fuel tank diagram VS1400 BOULEVARD S83 2009 (K9) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

1-1

4410039B20YAY
ref: 1-1

TANK ASSY,FUEL(BLACK)

€ 0.00

1-2

4410039B20YHG
ref: 1-2

TANK ASSY,FUEL(GRAY)

€ 0.00

1-3

4410039B30YAY
ref: 1-3

TANK ASSY,FUEL(BLACK)

€ 0.00

1-4

4410039B30YHG
ref: 1-4

TANK ASSY,FUEL(GRAY)

€ 0.00

6811139B00
ref: 2

EMBLEM,FUEL TANK,R

€ 63.00

6812139B00
ref: 3

EMBLEM,FUEL TANK,L

€ 0.00

4420038820
ref: 4

CAP SET,FUEL TANK

€ 107.50

4420024820
ref: 5

CAP SET,FUEL TANK

€ 150.50

6824104X50300
ref: 6

MOLDING

€ 6.00

4451138B01
ref: 7

CUSHION,FUEL TANK FR

€ 12.00

4425038B00019
ref: 8

BRACKET,FUEL TANK FR

€ 32.00

021127616B
ref: 9

SCREW

€ 0.00

4451238B00
ref: 10
56314-48B10

CUSHION

€ 6.00

015500635B
ref: 11

BOLT

€ 2.50

0932014013
ref: 12

CUSHION

€ 3.00

0918006274
ref: 13

SPACER(6.5X9X22.5)

€ 4.50

0932010020
ref: 14

CUSHION

€ 4.00
