SUSPENSION/SHOCK ABSORBER

VZ1600 BOULEVARD M95 2005 (K5) USA (E03)

Suspension/shock absorber diagram VZ1600 BOULEVARD M95 2005 (K5) USA (E03)

SUSPENSION/SHOCK ABSORBER VZ1600 BOULEVARD M95 2005 (K5) USA (E03)
SUSPENSION/SHOCK ABSORBER VZ1600 BOULEVARD M95 2005 (K5) USA (E03)
SUSPENSION/SHOCK ABSORBER VZ1600 BOULEVARD M95 2005 (K5) USA (E03)
prices are in EUR
ref
part #
description
quantity
461
KK461S1000
ref: 461
WASHER-SPRING,10MM
€ 1.50
11012
K110121283
ref: 11012
CAP
€ 5.50
16126
K161261043
ref: 16126
VALVE,AIR
€ 22.50
45014
K450140029
ref: 45014
SHOCKABSORBER,LH
K450140029
€ 507.00
45014A
K450140030
ref: 45014A
SHOCKABSORBER,RH
€ 507.00
92046
K920461296
ref: 92046
BEARING-NEEDLE
€ 8.00
92055
K920551130
ref: 92055
RING-O
€ 1.50
92075
K920751387
ref: 92075
DAMPER,SHOCKABSORBER
€ 10.50
92093
K920931552
ref: 92093
SEAL
€ 6.00
92152
K921521336
ref: 92152
COLLAR
€ 4.50
92200
K922001565
ref: 92200
WASHER,10.5X26X2.5
€ 2.00
92210
K922101288
ref: 92210
NUT,CAP,10MM
€ 4.50
